General Specifications

• Body Shape: Traditional Western Body Cutaway
• Scale Length: 650mm (25 9/16”)
• Body Length: 505mm (19 7/8")
• Total Length: 1046mm (41 3/16")
• Body Width: 412mm (16 1/4")
• Body Depth: 100-118mm (3 15/16”- 4 5/8”)
• Nut Width: 43mm (1 11/16”)
• String Spacing: 11.0mm
• Top Material: Solid Sitka Spruce A.R.E. w/Scalloped Bracing
• Back Material: Solid Mahogany
• Side Material: Solid Mahogany
• Neck Material: African Mahogany 3ply
• Fingerboard Material: Ebony
• Fingerboard Radius: R400mm (15 3/4")
• Bridge Material: Ebony
• Nut Material: Urea
• Saddle Material: Urea
• Bridge Pins: Black ABS with White Dot
• Tuners: Die-cast Chrome(TM29T)
• Body Binding: Mahogany + Cream
• Soundhole Inlay: Rosewood + Mahogany + Black + White
• Pickguard: Tortoise Pattern
• Body Finish: Gloss
• Neck Finish: Matt
• Electronics: SRT2 (SYSTEM71)
• Controls: Vol/Mic Type Select(2 types)/Treble/Bass/Undersaddle-Piezo Blend/AFR
• Connections: LINE OUT
• Strings: Elixir NANOWEB 80/20 Bronze Light
• Accessories: Soundhole Cover
• Hex Wrench:
• Case: Hard Bag
