Size/Weight

• Width: 1,430 mm
• Height: 932 mm (with music rest raised
• Depth: 1,237 mm
• Weight: 135 kg
• Packing Box Dimensions (W x H x D): 1,570 mm x 620 mm x 1,410 mm

Control Interfaces

• Number of Keys: 88
• Keyboard Type: GrandTouch™ keyboard
• Keyboard Touch Sensitivity: Hard2; Hard1; Medium; Soft1; Soft2; Fixed
• 88-key Linear Graded Hammers: Yes
• Keyboard Counterweight: Yes
• Number of Pedals: 3
• GrandTouch Pedals: Yes (with GP Response Damper)
• Assignable Pedal Functions: Sustain (Switch); Sustain (Continuous); Sostenuto; Soft; Pitch Bend Up; Pitch Bend Down; Rotary Speed; Vibe Rotor; Song Play/Pause
• Display Type: Full Dots LCD
• Display Language: English; Japanese
• Panel Type: Touch sensors
• Panel Language: English

Cabinet

• Key Cover Style: Sliding
• Music Rest: Yes
• Music Braces: Yes

Voices

• Piano Sound: Yamaha CFX; Bösendorfer Imperial
• Binaural Sampling: Yes (“CFX Grand” and “Bösendorfer” only)
• Virtual Resonance Modeling (VRM): Yes
• Grand Expression Modeling: Yes
• Number of Polyphony (Max.): 256
• Number of Preset Voices: 53 Voices + 480 XG Voices + 14 Drum/SFX Kits
• Compatibility: XG (GM); GS (for Song playback); GM2 (for Song playback)

Effects

• Reverb: 7 types
• Chorus: 3 types
• Brilliance: 7 types + User
• Insertion Effect: 12 types
• Intelligent Acoustic Control (IAC): Yes
• Stereophonic Optimizer: Yes
• Dual/Layers Function: Yes
• Split Function: Yes
• Duo Function: Yes

Songs

• Number of Preset Songs: 27 Voice Demo + 50 Classics + 303 Lesson Songs
• MIDI Recording: Number of Songs
• MIDI Recording: Number of Tracks
• MIDI Recording: Data Capacity
• Audio Recording (USB flash drive): Recording Time (max.)
• Compatible Data Format: Playback
• Compatible Data Format: Recording

Functions

• Piano Room: Yes
• Number of Rhythms: 20
• Metronome: Yes
• Tempo Range: 5 – 500
• Transpose: −12 – 0 – +12
• Tuning: 414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments)
• Scale Type: 7 types
• USB Audio Interface: 44.1 kHz; 24 bit; stereo
• Bluetooth: Audio; MIDI (varies by area)

Storage

• Internal Memory: Total maximum size approx. 1.4 MB
• External Drives: USB flash drive

Connectivity

• Headphones: Standard stereo phone jack (× 2)
• AUX IN: Stereo mini jack
• AUX OUT: Standard phone jack (L/L+R; R)
• USB TO DEVICE: Type A
• USB TO HOST: Type B
• DC IN: 24 V

Amplifiers and Speakers

• Amplifiers: (45 W + 45 W + 45 W) × 2
• Speakers: (16 cm + 8 cm with Waveguide + 2.5 cm (dome) with Waveguide) × 2; Spruce Cone Speaker

Power Supply

• AC Adaptor: PA-500
• Power Consumption: 60 W (When using PA-500 AC adaptor)
• Auto Power Off: Yes

Accessories

• Included Accessories: Owner’s Manual; “50 Classical Music Masterpieces” Music Book; Online Member Product Registration; Bench*; Power cord*/AC adaptor* (PA-500) *Varies by area
• Separately Sold Accessories: Headphones (HPH-150; HPH-100; HPH-50); Pedal unit (FC35); AC adaptor (PA-500); USB wireless LAN adaptor (UD-WL01)
