Size/Weight

• Product Width: 1,426 mm (Polished finish 1429 mm)
• Product Height: 868 mm (Polished finish 872 mm)
• Product Depth: 612 mm (Polished finish 612 mm)
• Product Weight: 82 kg (Polished finish 85 kg)
• Packing Box Width: 1,567 mm
• Packing Box Height: 716 mm
• Packing Box Depth: 745 mm

Control Interface

• Number of Keys: 88
• Keyboard Type: GrandTouch Keyboard - wooden keys (white only) synthetic ebony and ivory key tops escapement
• Touch Sensitivity: Hard2 Hard1 Medium Soft1 Soft2
• 88-key Linear Graded Hammers: Yes
• Counterweight: Yes
• Number of Pedals: 3
• Half Pedal: Yes
• GrandTouch Pedals: Yes (with GP Response Damper)
• Pedal Functions: Sustain Sostenuto Soft Glide Song Play/Pause Style Start/Stop Volume etc.
• Display Type: TFT Color LCD (Touch Screen)
• Display Size: 800 × 480 dots 9.0 inch
• LCD Brightness: Yes
• Touch Screen: Yes
• Color: Yes
• Score Display Function: Yes
• Lyrics Display Function: Yes
• Text Viewer Function: Yes
• Language: English German French Spanish Italian Japanese
• Panel Language: English

Cabinet

• Key Cover Style: Folding
• Music Rest: Yes
• Music Clips: Yes

Voices

• Piano Sound: Yamaha CFX Bösendorfer Imperial
• Binaural Sampling: Yes (CFX Concert Grand and Bösendorfer Grand Voice only)
• Key-off Samples: Yes
• Smooth Release: Yes
• Virtual Resonance Modeling (VRM): Yes
• Grand Expression Modeling: Yes
• Number of Polyphony (Max.): 256
• Number of Voices: 1,605 Voices + 58 Drum/SFX Kits + 480 XG Voices
• Featured Voices: 17 VRM Voices 36 Super Articulation2 Voices 301 Super Articulation Voices
• Voice Edit: Yes
• Compatibility: XG GS GM GM2

Effects

• Reverb: 65 Preset + 30 User
• Chorus: 107 Preset + 30 User
• Master Compressor: 5 Preset + 30 User
• Master EQ: 5 Preset + 30 User
• Part EQ: 27 Parts
• Intelligent Acoustic Control (IAC): Yes
• Stereophonic Optimizer: Yes
• Insertion Effect: 358 Preset + 30 User
• Variation Effect: 358 Preset + 30 User
• Vocal Harmony: 54 Preset + 60 User
• Dual/Layers Function: Yes
• Split Function: Yes

Accompaniment Styles

• Number of Preset Styles: 675
• Fingering: Single Finger Fingered Fingered On Bass Multi Finger AI Fingered Full Keyboard AI Full Keyboard
• Style Control: INTRO × 3 MAIN VARIATION × 4 FILL × 4 BREAK ENDING × 3
• Style Creator: Yes

Songs

• Number of Preset Songs: 50 Classics + 303 Lesson Songs + 60 Popular
• Number of Tracks: 16
• Data Capacity: approx. 3 MB/Song
• Recording Function: Yes
• Playback: SMF (Format 0 Format 1) XF
• Recording: SMF (Format 0)

Functions

• Demo: Yes
• Number of Buttons: 8
• Control: Registration Sequence Freeze
• Number of Records: 2.5
• Lesson/Guide: Follow Lights Any Key Karao-Key Your Tempo (with guide lamps)
• Guide Lamp: Yes
• Performance Assistant Technology (PAT): Yes
• Piano Room: Yes
• USB Audio Recorder: Playback
• Recording: WAV (44.1kHz 16bit stereo) MP3 (MPEG-1 Audio Layer-3)
• Time Stretch: Yes
• Pitch Shift: Yes
• Vocal Cancel: Yes
• Metronome: Yes
• Tempo Range: 5 – 500 Tap Tempo
• Transpose: −12 – 0 – +12
• Tuning: 414.8 – 440 – 466.8 Hz (approx. 0.2 Hz increments)
• Scale Type: 9 Types
• Display Out: Yes (by using a commercially available USB display adaptor)
• Bluetooth: Yes (Audio)

Storage and Connectivity

• Internal Memory: approx. 2 GB
• External Drives: USB flash drive
• Headphones: Standard stereo phone jack (× 2)
• Microphone: Mic/Line in (standard mono phone jack) Input volume
• MIDI: IN OUT THRU
• AUX IN: Stereo mini jack
• AUX OUT: L/L+R R
• AUX Pedal: Yes
• USB TO DEVICE: Yes (× 2)
• USB TO HOST: Yes

Amplifiers and Speakers

• Amplifiers: (40 W + 30 W + 20 W) × 2 + 80 W
• Speakers: 16 cm + 5 cm + 2.5 cm dome × 2 + 20 cm Spruce Cone Speaker Twisted Flare Port

Power Supply

• Power Consumption: 64W

Accessories (Sold Separately)

• Accessories: Headphones (HPH-150 HPH-100 HPH-50) Footswitches (FC4A FC5) Foot controller (FC7) USB wireless LAN adaptor (UD-WL01)
