SPECIFICATIONS

Specifications

Engine

Engine type: 4-stroke
Bore x stroke: 65.0 mm x 75.0 mm
Displacement: 996 cm³
Prop shaft output at mid range: 44.1 kW / 5500 rpm
Full throttle operating range: 5000 - 6000 rpm
Lubrication system: Wet sump
Ignition / advance system: CDI
Gear ratio: 2.33 (28:12)
Starter system: Electric
No. of cylinders/configuration: 4/In-line SOHC
Fuel Induction System: EFI

Dimensions

Fuel tank capacity: Separate 25 litres, Oil pan capacity: 2.1litres
Recommended boat transom height: L527
Weight without propeller: 114kg

Additional Features

Lighting Coil / Alternator: 12V -16Awith recti er/regulator
Trim & tilt method: Power Trim & Tilt
Remark: The kW data in this sheet is based on the ICOMIA 28 standard measured at the prop shaft
Propeller: Optional
Variable Trolling RPM: With DN Gauges or m-f tiller handle
Control: Remote Control
Engine immobiliser: YCOP optional

Features

Ultra-smooth 4-cylinder refinement with EFI
Digital network gauges
Variable trolling RPM control
Wide Range Power Trim & Tilt
Compact shape and solid one-piece top cowling
Advanced warning systems

Ultra-smooth 4-cylinder refinement with EFI

Whether strokes or cylinders Yamaha understands the power of Four. Which is how the world's pioneer in 4-stroke technology has brought added refinement to the 4-cylinder configuration with a powerful long stroke design for the EFI equipped 60hp - to deliver ultra-smooth useable power with low noise and vibration levels.

Digital network gauges

The 60hp is compatible with our Digital Network Gauges which deliver the information needed to maximise engine performance and efficiency including a Multifunction Tachometer with RPM Hours Run Trim Angle Oil Pressure. Warning lamps and Variable RPM control - and a Speed/Fuel Management Gauge with Speed Tank Capacity and Fuel Economy.

Variable trolling RPM control

With the press of a button on the optional Digital Network's Tachometer – or via the variable trolling RPM switch on the optional multi-function tiller handle – the driver can adjust the engine speed for relaxed trolling in precise steps of 50 RPM, between 620 and 900 RPM.

Wide Range Power Trim & Tilt

Discover the versatility and power of a Yamaha engine. Quick response via push button control makes trim and tilt adjustments swift smooth and easy across a wide trim range. The negative trim settings are particularly useful to improve acceleration and bring the boat onto the plane quickly.

Compact shape and solid one-piece top cowling

With the advanced design and modest overall dimensions of this 4-cylinder unit our engineers have produced a remarkably compact 996cc powerhouse but with a low weight that is comparable to a conventional 3-cylinder engine. So the 60hp has a power-to-weight ratio that makes it the ideal choice for a wide range of boats.

Advanced warning systems

Yamaha engines are renowned for their reliability and for how well they hold their value. The comprehensive warning systems on this engine measure oil pressure engine temperature and other key variables to provide clear audio/visual warnings of any problems. If a fault occurs RPM are automatically reduced to protect your engine as you head for shore.
