Specifications
General Specifications
Keyboard Control interface
Tone Generator
Performance Recorder
Sequencer
Functions
Other
Features
Recreate everything from vintage warmth to edgy, aggressive synth sounds. Features a 16-polyphony virtual analog system integrated with Motion Control, boasting two filters, 10 filter types, pulse width modulation, Oscillator Self Sync, ring modulation, wave shaping/folding, and voltage drift/aging settings to accurately simulate classic hardware behavior.
Experience unmatched realism and digital precision. The improved AWM2 engine features an advanced wave memory architecture supporting 128 elements per part and double the waveforms for pristine acoustic instruments like pianos and strings, while the 8-operator FM-X engine delivers characteristic cutting-edge digital tones.
Massive sonic headroom prevents note stealing. The flagship system delivers up to 400 notes of combined polyphony across all three engines, while the compact performance tier offers a total of 268 notes (128 AWM2, 128 FM-X, and 12 AN-X) for complex, multi-layered live arrangements.
Unified multi-engine design for dynamic sound design. Interact with your music using Motion Sequences to automate synth and effect parameters perfectly in tempo sync, use the Envelope Follower to shape your sound using incoming audio inputs, and orchestrate complex layers in real time.
Control up to 280 modulation parameters simultaneously with a single, simple gesture. Instantly transform a subtle texture into a massive sonic wall, making complicated, multi-layered sound changes fluid and intuitive during live performance.
Faders, knobs, pitch bend, and mod wheels are upgraded to ultra-fine resolution. The hardware performs noticeably smoother than its predecessors, eliminating digital stepping for continuous, organic parameter sweeping.
Take full command of your live performance. Features dedicated Part and Scene selection buttons to intuitively control 8 parts per performance layout, drastically improving layout navigation and adding clear physical dimensions to stage play.
Unprecedented stage and studio integration. Free for registered owners, this software replica (VST3, AU) replicates the entire synthesizer engine inside your favorite DAW, allowing you to create, edit, and mix your performances anywhere without needing the physical hardware.
Faster and more intuitive sound creation. Combines a central color touchscreen with six new display display knobs, a Navigation button to jump from the surface of a sound to its deepest parameters, and a secondary LCD screen for instantaneous filtering and oscillator editing via Page Jump functionality.
Flagship touch response tailored to distinguish subtle nuances. Choose between the premium FSX keyboard with Channel Aftertouch (61 and 76-key variations) or the groundbreaking GEX 88-key weighted action featuring Polyphonic Aftertouch for individual key sound modulation, synthetic ebony/ivory keytops, and direct velocity matching.
Massive data storage capacity expansion. Features an approximate 2x memory upgrade over predecessor models, offering up to 10.7 GB of AWM2 factory presets and an expanded 1.9 GB of non-volatile User Flash memory for custom sample loading.
Studio-grade sonic texturing. The Virtual Circuitry Modeling (VCM) processing engine faithfully simulates the rich, enveloping, and organic rotational motion of a classic vintage rotary speaker cabinet.
Simplified studio studio workflow. Operates as a multichannel 10-output/4-input audio interface at 44.1kHz alongside next-generation MIDI 2.0 data compliance, streaming high-resolution velocity, pitch bend, and modulation data through a single USB-C cable.
Dedicated DAW Remote button maps physical faders to control Cubase, Logic, ProTools, and Live mixers. Includes Cubase AI bundle license for immediate multi-track recording, stereo A/D inputs with dual insertion effects for external instruments, 4 pedal inputs, 8 faders, and 4 assignable control knobs.
